8″ thru 36″ Angle Brace
admin2025-06-25T17:47:48+00:00Part No. Size Between Holes Wt - lbs G2452-8EG 8" 7 1/2" 1.19 G2452EG 16" 13 1/4" 2.18
2-HOLE ADJUSTABLE CORNER ANGLE
admin2025-05-27T16:49:15+00:00Part No. Size Wt. Each lbs Wt. Each kg G1498EG 4 7/8 (123.83) 0.58 (0.26) G1499EG 6 7/8 (174.63) 0.85 (0.39) Unless otherwise specified, all dimensions on drawings and in charts are in inches and dimensions shown in parentheses are in millimeters
2-HOLE ADJUSTABLE CORNER ANGLE
admin2025-06-24T17:04:03+00:00Part No. Wt - lbs Length in (mm) End to mid Slot Size in (mm) Depth in (mm) Slot Size in (mm) G1750EG 0.35 2 5/8 (66.7) 1.42" (36.1) 1 5/8" (41.3) 1 1/2" x 9/16" (38.1 x 14.3) G1498EG 0.58 4 7/8 (123.8) 2 1/2" (63.5) 1 7/8" (47.6) 2 1/2" x 9/16" (63.5
