Part No. Wt - lbs G1130EG 1.62 Material is 1-5/8″ [41.3] wide x 1/4″ [6.3] thick unless specified.  Holes are 9/16″ (14.3) diameter 13/16″ [20.6] center to edge on 1-7/8″ [47.6] centers unless specified.

Part No. Wt - lbs G1747EG 0.70 Material is 1-5/8″ [41.3] wide x 1/4″ [6.3] thick unless specified.  Holes are 9/16″ (14.3) diameter 13/16″ [20.6] center to edge on 1-7/8″ [47.6] centers unless specified.

Part No. Size (mm) Wt. Each lbs Wt. Each kg G1498EG 4 7/8 (123.83) 0.58 0.26 G1499EG 6 7/8 (174.63) 0.85 0.39 Unless otherwise specified, all dimensions on drawings and in charts are in inches and dimensions shown in parentheses are in millimeters. Material is 1-5/8″ [41.3] wide x 1/4″ [6.3] thick unless specified.  Holes

Part No. Wt - lbs G2484EG 1.51 Material is 1-5/8″ [41.3] wide x 1/4″ [6.3] thick unless specified.  Holes are 9/16″ (14.3) diameter 13/16″ [20.6] center to edge on 1-7/8″ [47.6] centers unless specified.

Part No. Wt - lbs G2235EG 1.27 Material is 1-5/8″ [41.3] wide x 1/4″ [6.3] thick unless specified.  Holes are 9/16″ (14.3) diameter 13/16″ [20.6] center to edge on 1-7/8″ [47.6] centers unless specified.

Part No. Wt - lbs G1325EG 0.71 Material is 1-5/8″ [41.3] wide x 1/4″ [6.3] thick unless specified.  Holes are 9/16″ (14.3) diameter 13/16″ [20.6] center to edge on 1-7/8″ [47.6] centers unless specified.

Part No. Wt - lbs G1458EG 0.52 Material is 1-5/8″ [41.3] wide x 1/4″ [6.3] thick unless specified.  Holes are 9/16″ (14.3) diameter 13/16″ [20.6] center to edge on 1-7/8″ [47.6] centers unless specified.

Part No. Wt - lbs G1359EG 1.02 Material is 1-5/8″ [41.3] wide x 1/4″ [6.3] thick unless specified.  Holes are 9/16″ (14.3) diameter 13/16″ [20.6] center to edge on 1-7/8″ [47.6] centers unless specified.

Part No. Wt - lbs G1728EG 1.40

Part No. Wt - lbs G1357EG 0.65 Material is 1-5/8″ [41.3] wide x 1/4″ [6.3] thick unless specified.  Holes are 9/16″ (14.3) diameter 13/16″ [20.6] center to edge on 1-7/8″ [47.6] centers unless specified.
