Part No.	Wt – lbs	Length in  (mm)	Uniform Load lbs  (kN)
G2542EG	4.92	12  (304.8)	1,800  (8.01)
G2543EG	6.78	18  (457.2)	1,200  (5.34)
G2544EG	8.68	24  (609.6)	1,000  (4.45)
G2545EG	10.50	30  (762.0)	800  (3.56)
G2546EG	12.52	36  (914.4)	650  (2.89)



Load shown for bracket mounted on 12 gauge channel
